Name：YLH01 Full Electric Floor Crane, Engine Hoist
Model：YLH01
Product Introduction：Fully powered shop cranes (power hoist & power in/out boom) for moving loads quickly, easily, and safely. 24V DC drive and lift motor handles heavy-duty jobs. The crane has an adjustable boom that allows maximum adjustment and versatility to lift a variety of loads. The boom is operated with a manual hydraulic hand pump. The boom can also be telescoped out for greater reach. The counterbalanced design eliminates the need for a front leg, making the unit easier to maneuver and is ideal for reaching narrow, hard-to-reach areas, hard-to-reach areas.

Fully powered shop cranes (power hoist & power in/out boom) for moving loads quickly, easily, and safely. 24V DC drive and lift motor handles heavy-duty jobs.

The crane has an adjustable boom that allows maximum adjustment and versatility to lift a variety of loads. The boom is operated with a manual hydraulic hand pump. The boom can also be telescoped out for greater reach. The counterbalanced design eliminates the need for a front leg, making the unit easier to maneuver and is ideal for reaching narrow, hard-to-reach areas, hard-to-reach areas.

Model		YLH
Boom length	mm	1125	1980	2780
Load Capacity	kg	1000	550	200
Lift Motor	kw	2.2
Drive Motor	kw	0.75
Battery		12V/120Ah×2
Front Wheel	mm	∅150×70
Drive Wheel	mm	∅250×80
Travel Speed	km/h	5
Overall Size	mm	2200×1015×1950
Battery Size	mm	406×172×211
Net Weight	kg	720
